PowerPlex® Y23 System

Part Numbers: DC2305, DC2320, DM6571

DC2305_PowerPlex--Y23-System--50rxn
10436MA-W
DM6571_Stabilizer-Reagent_3
DC2305_PowerPlex--Y23-System--50rxn
customize-this-small

23のY-STRローカス増幅用5色蛍光マルチプレックスPCR

  • 女性由来DNAの混在下でも高感度
  • 阻害剤に高耐性
  • ファーストサイクリングにより増幅時間がおよそ半分に

Choose a product

Size

選択製品のカタログ番号: DC2305

Please Enquire
This product is discontinued
This product is available under our Early Access program - Learn More
This product is available under our Catalog (FT) program - Learn More
PowerPlex® Y23 System
PowerPlex® Y23 System/50 reactions
Your price:
Change Configuration

Amplify 23 Y-STR Loci in a Single Reaction

【PowerPlex® Y23 Systemは2016年5月より、新規蛍光色素により標識されたWEN ILS 500 Y23がインターナルレーンスタンダードとして付属します。詳細はこちらをご覧ください】

PowerPlex® Y23 Systemは23ローカス、5色の Y-STR マルチプレックスシステムで法医学的ケースワークサンプル、データベースサンプルおよび親子鑑定サンプルの遺伝子タイピング用にデザインされています。キットには従来品のPowerPlex® Y Systemに含まれる12ローカスに加えてAmpFlSTR® Y-filer®に含まれる5ローカス、さらに新しい6ローカスを加えています。
PowerPlex® Y23 Systemは少量の鋳型や男性および女性の混合DNAなどの抽出DNAサンプルを用いた分析に使用できます。
PowerPlex® Y23 Systemはダイレクト増幅に適応しY-STRデータベース構築作業をより効率化することができます。
FTA® カードパンチや前処理済のスワブ、 Bode Buccal DNA Collector™パンチ、S&S 903パンチなど様々なサンプルタイプより増幅を行うことができます。
ファーストサイクリング条件は増幅時間をほぼ半分に短縮し、サンプル処理時間の短縮と併せることで1回あたりの時間を大幅に節約することができます。
PowerPlex® Y23 Systemは多くの既知増幅阻害剤に耐性を持ち、このキットの頑健性により阻害成分を含むサンプルからでも解釈可能なデータを得ることができます。

PowerPlex® Y23 Systemは2013年1月にNDISの承認を取得しました。


  • より強力なSTR分析：23ローカスを用いた高い識別力は偽陽性を低減
  • 過剰な女性由来DNAサンプルからでも有効なプロファイリング：女性由来DNAの混在下でも高感度（<0.1ng、比率1:6000）
  • データベース構築工程を効率化：ダイレクト増幅が可能
  • 増幅時間が飛躍的に短縮：ファーストサイクリングにより増幅時間がおよそ半分に
  • 困難なケースワークサンプルでも完全なプロファイルを作成：タンニン酸、ヘマチン、フミン酸などの阻害剤にも高耐性
  • シンプルなワークフローと製品管理：1つのキットでケースワーク構築用とデータベース用に対応

  • Y-STR分析
  • PowerPlex® マルチプレックス
  • ダイレクト増幅
  • ケースワーク
  • データベース構築
  • 親子鑑定
  • 近親者探索
  • 血縁鑑定
  • ファーストサイクリング
  • 混合液分析
    •

New!

Learn how to interpret results from Y-STR DNA typing using the Y-Chromosome Haplotype Reference Database (YHRD), a free resource.

Download PDF

ForensicGrade

Promega forensic products are manufactured in alignment with the ISO 18385 standard. This standard ensures minimal risk of human DNA contamination for products used to collect, store and analyze biological materials for forensic purposes. Learn more.

Amplify Only Male DNA

The PowerPlex® Y23 System can successfully amplify trace amounts of male DNA, even in the presence of overabundant amounts of female DNA.

13065MA-W
Amplification of decreasing amounts of male DNA in the presence of 1µg of female DNA with two Y-STR kits: PowerPlex® Y23 System and Yfiler® Plus PCR Amplification Kit. Amplified products were separated on an Applied Biosystems® 3500xL Genetic Analyzer (1.2kV, 24-second injection).

Obtain Full Profiles from the Most Challenging Samples

The PowerPlex® Y23 System is a robust multiplex that is tolerant of many amplification inhibitors, including hematin, tannic acid and humic acid. The robust performance of the kit results in more interpretable data and less need for re-amplification of inhibitor-laden samples.

13066MA-W
Amplification of 500pg of male DNA (PowerPlex® Y23 System) or 1.0ng of male DNA (Yfiler® Plus PCR Amplification Kit) in the presence of increasing amounts of common inhibitors. DNA was amplified for 30 cycles, and amplified products were separated on an Applied Biosystems® 3500xL Genetic Analyzer (1.2kV, 24-second injection).

Streamline Workflows with Direct Amplification

The PowerPlex® Y23 System also is compatible with direct amplification, enabling streamlined Y-STR databasing efforts. Amplification can be successfully performed with sample types such as FTA® card punches as well as pretreated swabs, Bode Buccal DNA Collector™ punches or S&S 903 punches. Faster cycling conditions cut amplification time almost in half. Moreover, reduced sample-processing time and faster cycling conditions provide a significant time savings in every run.

Buccal Sample on FTA® Card
10433MA-W
Amplification of DNA from two 1.2mm punches from buccal cells on an FTA® card (direct amplification) using 27 cycles and the PowerPlex® Y23 System. Amplified products were separated using an Applied Biosystems® 3130xl Genetic Analyzer (3kV, 5-second injection).
Swab Sample with SwabSolution™ Reagent
13067MA-W
Amplification of DNA from a cotton swab pretreated with SwabSolution™ Reagent using 26 cycles and the PowerPlex® Y23 System. Amplified products were separated on an Applied Biosystems® 3130xl Genetic Analyzer (3kV, 5-second injection).
Buccal Sample with PunchSolution™ Reagent
13068MA-W
Amplification of one 1.2mm Bode Buccal DNA Collector™ punch preprocessed with the PunchSolution™ Reagent using 26 cycles and the PowerPlex® Y23 System. Amplified products were separated on an Applied Biosystems® 3130xl Genetic Analyzer (3kV, 5-second injection).

Rapid Processing Solutions for PowerPlex® Systems

The 5X AmpSolution™ Reagent, SwabSolution™ Kit and PunchSolution™ Kit allow fast and simple processing of swabs and punches for analysis with various PowerPlex® Systems, including the PowerPlex® Fusion, 21, 18D, 16 HS, ESX, ESI, CS7 and Y23 Systems. These products are intended for preparation of single-source reference, database and paternity samples where sample purification is unnecessary.

Which Product is Right for Me?

プロトコール

Complete Protocol

Quick Protocols

製品仕様

You are viewing: DC2305 Change Configuration

選択製品の構成品内容

Item Part # Size Concentration Available Separately

2800M Control DNA

 DD710A 1 × 25μl 10ng/μl View Product
PowerPlex® Y23 5X Master Mix DP108A 1 × 250μl

Water, Amplification Grade

 DW099A 1 × 1,250μl View Product
PowerPlex® Y23 Allelic Ladder Mix DG248B 1 × 25μl

WEN Internal Lane Standard 500 Y23

 DG520A 1 × 200μl View Product
PowerPlex® Y23 10X Primer Pair Mix DK209B 1 × 125μl

SDS

Search for SDS

分析証明書

Search by lot number

使用制限

Not For Medical Diagnostic Use.

保存条件

BB

パテントおよび免責条項

U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.

TMR-ET, CXR-ET and WEN dyes are proprietary.

製品仕様

You are viewing: DC2320 Change Configuration

選択製品の構成品内容

Item Part # Size Concentration Available Separately

2800M Control DNA

 DD710A 1 × 25μl 10ng/μl View Product

Water, Amplification Grade

 DW099A 5 × 1,250μl View Product
PowerPlex® Y23 Allelic Ladder Mix DG248B 4 × 25μl

WEN Internal Lane Standard 500 Y23

 DG520A 1 × 200μl View Product
PowerPlex® Y23 10X Primer Pair Mix DK209B 4 × 125μl
PowerPlex® Y23 5X Master Mix DP108A 4 × 250μl

SDS

Search for SDS

分析証明書

Search by lot number

使用制限

Not For Medical Diagnostic Use.

保存条件

BB

パテントおよび免責条項

U.S. Pat. No. 9,139,868, European Pat. No. 2972229, Japanese Pat. No. 6367307 and other patents pending.

TMR-ET, CXR-ET and WEN dyes are proprietary.

製品仕様

You are viewing: DM6571 Change Configuration

選択製品の構成品内容

Item Part # Size

Stabilizer Reagent

 DM657A 1 × 0.25ml

SDS

Search for SDS

分析証明書

Search by lot number

使用制限

For Research Use Only. Not for Use in Diagnostic Procedures.

保存条件

CC

技術資料

技術記事

サイテーション

Software and Firmware

その他

類似製品

PowerPlex® 21 System

ヒト個人識別用マルチプレックスSTRシステム

DC8902, DC8942

PowerPlex® Fusion 6C System

27ローカス同時増幅の6色蛍光検出システム

DC2705, DC2720, DC2780

PowerPlex® ESX 16 and ESI 16 Fast Systems

ENFSI推奨のSTRローカスを同時増幅、5色蛍光で検出

DC1610, DC1611, DC1630, DC1631, DC1620, DC1621

PowerPlex® ESX 17 and ESI 17 Fast Systems

ENFSI推奨のSTRローカスを同時増幅、5色蛍光で検出

DC1710, DC1711, DC1720, DC1721, DC1731, DC1730

関連製品

PowerPlex® Matrix Standards

PowerPlex® Systemを使用するために用いる蛍光標識DNA断片

DG4800, DG4850, DG4900, DG5010

PowerQuant® System

4種類のターゲットを検出するプローブベースの5色蛍光ヒト特異的定量PCRアッセイキット

PQ5002, PQ5008, DS1221

2800M Control DNA

ヒトのSTR解析に

DD7101, DD7251

5X AmpSolution™ Reagent, PunchSolution™ Kit and SwabSolution™ Kit

スワブ、パンチの迅速・シンプルな調製法

DM1231, DC9271, DC8271
