Lumit® IL-1β Human/Mouse Immunoassay
No-Wash Immunoassay for IL-1β Detection in Cells
- Fast add-and-read protocol performed directly on cells
- Luminescent detection with just a standard plate-reading luminometer
- Scalable to 96- or 384- well plates, protocols included
- Pack sizes show assay number for 96-well plates
Catalog Number:
Choose a product
Size
Catalog Number: W6010
Catalog Number: W6011
Catalog Number: W6012
Catalog Number: W7010
Catalog Number: W7011
Catalog Number: W7012
Catalog Number: W116A-C
Catalog Number: W119A-C
面倒な洗浄ステップの無いインフラマソーム活性化測定
Lumit™ IL-1βImmunoassayは、シンプルな無洗浄プロトコルを使用して、細胞培養サンプル中のIL-1βを定量的に測定します。サンプルに標識抗体、検出試薬を加え、標準のプレートフォーマットルミノメーターを使用して発光シグナルを測定するだけです。プロトコル全体が70分以内に完了します！このアッセイは、培養中の細胞でそのまま、あるいは培地を別のアッセイプレートに移して測定することができます。
Lumit™IL-1βイムノアッセイのしくみ
IL-1βに対する一次抗体は、特異的かつ高感度な検出を行うために選別され、NanoBiT®ルシフェラーゼのLgBiTおよびSmBiTサブユニットで標識されています。IL-1βの存在下で、サブユニットが会合し、活性を有するルシフェラーゼ酵素を形成します。最適化された基質を添加すると、IL-1βレベルに比例した明るい発光シグナルが生成されます。
シンプルなワンプレートプロトコル、洗浄ステップなし！
Lumit™ 検出法の広いダイナミックレンジ
Lumit™ 検出のピコモルからナノモルのリニアレンジは、ほとんどの細胞モデルで予想される濃度をカバー。
|
Assay |
IL-1β (Human) Immunoassay |
IL-1β (Mouse) Immunoassay |
|
Limit of Detection (LOD) |
10pg/ml (3 SD above background) |
8pg/ml (3 SD above background) |
|
Dynamic Range |
22pg/ml – 40ng/ml |
11pg/ml – 20ng/ml |
|
Minimal Detectable Dose (MDD) |
7pg/ml (2 SD above background) |
5pg/ml (2 SD above background) |
|
Assay Time |
70 minutes |
|
|
Sample Type |
Cell culture supernatants |
|
SD=Standard Deviation
ハイスループットNLRP3インフラマソーム阻害剤スクリーニング
Lumit™ IL-1βイムノアッセイの試薬添加＆測定だけのシンプルなフォーマットにより、IL-1β放出モジュレーターのハイスループットスクリーニングが可能。
NLRP3インフラマソーム阻害剤であるMCC950は、カスパーゼ1の活性化と成熟IL-1βの放出を阻害。分化したTHP-1細胞（5×10 4 /ウェル）にMCC950の段階希釈液を加え、続いてLPS（20 EU / ml）またはビークルを加えました。Lumit™IL-1β（ヒト）イムノアッセイは5時間後に実施。
Featured Publication
This peer-reviewed study "Interrogating direct NLRP3 engagement and functional inflammasome inhibition using cellular assays" examines the direct engagement and functionality of NLRP3 pathway activity in cells using several mechanistic assays, including the Lumit® IL-1β Immunoassay and Caspase-Glo 1 Inflammasome Assay.
Explore Additional Cytokine Detection Assays
We offer a growing portfolio of assays to detect cytokines in cell culture samples.
Can’t find your target in the list?
Please enquire about early access to new assays in development.
For a biotech that understands time is of significant value, the Lumit® Immunoassays are an essential way for us to gather reliable data fast so that we can reach conclusions and make decisions sooner.
Jonathan Chow, Principal Scientist, Corner Therapeutics
Specifications
Catalog Number:
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Lumit® Detection Substrate B |
VB405A | 1 × 160μl | |
Lumit® Detection Buffer B |
VB406A | 1 × 3.2ml | |
Human IL-1β Standard |
W116A | 1 × 25μl | 10μg/ml |
Anti hIL-1β mAb-SmBiT, 1000X |
W117A | 1 × 15μl | |
Anti hIL-1β mAb-LgBiT, 1000X |
W118A | 1 × 15μl |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
U.S. Pat. Nos. 9,797,889, 9,797,890, 10,107,800 and 11,493,504; European Pat. No. 2970412; Japanese Pat. Nos. 7280842 and 7532562; and other patents and patents pending.
U.S. Pat. No. 8,809,529, European Pat. No. 2635582, Japanese Pat. No. 5889910 and other patents and patents pending.
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Lumit® Detection Substrate B |
VB405B | 1 × 1.25ml | |
Lumit® Detection Buffer B |
VB406B | 1 × 25ml | |
Human IL-1β Standard |
W116A | 1 × 25μl | 10μg/ml |
Anti hIL-1β mAb-SmBiT, 1000X |
W117B | 1 × 150μl | |
Anti hIL-1β mAb-LgBiT, 1000X |
W118B | 1 × 150μl |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
U.S. Pat. Nos. 9,797,889, 9,797,890, 10,107,800 and 11,493,504; European Pat. No. 2970412; Japanese Pat. Nos. 7280842 and 7532562; and other patents and patents pending.
U.S. Pat. No. 8,809,529, European Pat. No. 2635582, Japanese Pat. No. 5889910 and other patents and patents pending.
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Lumit® Detection Substrate B |
VB405A | 5 × 160μl | |
Lumit® Detection Buffer B |
VB406A | 5 × 3.2ml | |
Human IL-1β Standard |
W116A | 1 × 25μl | 10μg/ml |
Anti hIL-1β mAb-SmBiT, 1000X |
W117A | 5 × 15μl | |
Anti hIL-1β mAb-LgBiT, 1000X |
W118A | 5 × 15μl |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
U.S. Pat. Nos. 9,797,889, 9,797,890, 10,107,800 and 11,493,504; European Pat. No. 2970412; Japanese Pat. Nos. 7280842 and 7532562; and other patents and patents pending.
U.S. Pat. No. 8,809,529, European Pat. No. 2635582, Japanese Pat. No. 5889910 and other patents and patents pending.
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Lumit® Detection Substrate B |
VB405A | 1 × 160μl | |
Lumit® Detection Buffer B |
VB406A | 1 × 3.2ml | |
Mouse IL-1β Standard |
W119A | 1 × 25μl | 10μg/ml |
Anti mIL-1β mAb-SmBiT, 1000X |
W120A | 1 × 15μl | |
Anti mIL-1β mAb-LgBiT, 1000X |
W121A | 1 × 15μl |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
U.S. Pat. Nos. 9,797,889, 9,797,890, 10,107,800 and 11,493,504; European Pat. No. 2970412; Japanese Pat. Nos. 7280842 and 7532562; and other patents and patents pending.
U.S. Pat. No. 8,809,529, European Pat. No. 2635582, Japanese Pat. No. 5889910 and other patents and patents pending.
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Lumit® Detection Substrate B |
VB405B | 1 × 1.25ml | |
Lumit® Detection Buffer B |
VB406B | 1 × 25ml | |
Mouse IL-1β Standard |
W119A | 1 × 25μl | 10μg/ml |
Anti mIL-1β mAb-SmBiT, 1000X |
W120B | 1 × 150μl | |
Anti mIL-1β mAb-LgBiT, 1000X |
W121B | 1 × 150μl |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
U.S. Pat. Nos. 9,797,889, 9,797,890, 10,107,800 and 11,493,504; European Pat. No. 2970412; Japanese Pat. Nos. 7280842 and 7532562; and other patents and patents pending.
U.S. Pat. No. 8,809,529, European Pat. No. 2635582, Japanese Pat. No. 5889910 and other patents and patents pending.
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Lumit® Detection Substrate B |
VB405A | 5 × 160μl | |
Lumit® Detection Buffer B |
VB406A | 5 × 3.2ml | |
Mouse IL-1β Standard |
W119A | 1 × 25μl | 10μg/ml |
Anti mIL-1β mAb-SmBiT, 1000X |
W120A | 5 × 15μl | |
Anti mIL-1β mAb-LgBiT, 1000X |
W121A | 5 × 15μl |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
U.S. Pat. Nos. 9,797,889, 9,797,890, 10,107,800 and 11,493,504; European Pat. No. 2970412; Japanese Pat. Nos. 7280842 and 7532562; and other patents and patents pending.
U.S. Pat. No. 8,809,529, European Pat. No. 2635582, Japanese Pat. No. 5889910 and other patents and patents pending.
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Human IL-1β Standard |
W116A | 1 × 25μl | 10μg/ml |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
選択製品の構成品内容
| Item | Part # | Size | Concentration |
|---|---|---|---|
Mouse IL-1β Standard |
W119A | 1 × 25μl | 10μg/ml |
SDS
Search for SDS分析証明書
使用制限
For Research Use Only. Not for Use in Diagnostic Procedures.保存条件
Please see the Protocol for detailed storage conditions.
